Price of 5 Ton-23m and H-9m European-spec Single Girder Overhead Crane for Sale to India

Price of 5 Ton-23m and H-9m European-spec Single Girder Overhead Crane for Sale to India:

Technical specifications of 5 Ton-23m and H-9m European-spec Single Girder Overhead Crane for Sale to India:

Item	Single Girder Overhead Crane
Lifting capacity	5 t
Lifting height	9 m
Span	23 m
Power supply	380V/50Hz/3Phase
Control	Remote control +pendent control
Working class	A5(FEM 2m)
Long traveling speed	2-20m/min (inverter control)
Cross traveling speed	2-20m/min (inverter control)
Lifting speed	0.8/5m/min
Lifting power	0.8/4.9kw
Cross traveling power	0.45kw
Long crane traveling power	2x1.1kw
Recommended rail	P22
Working temperature	-20℃ ~ +40℃
Cross power	Festoon cable
Insulation grade	F
Protection grade	IP54
Emergency stop	when meet the emergency the operator can press the emergency stop button and the crane power will be off.
Anti-collision system	Included
Phase protection relays	Included
Limit switch	Included
Voltage Low Protect device	Included
Emergency stop action	Included
Ground fault protection	Included
Short-circuit protection	Included
Over-heating protection	Included
Power-off protection	Included
Country of origin	China

Recommended Crane Rail Specification:

5 Ton-23m and H-9m European-spec Single Girder Overhead Crane for Sale to India:

A mid-sized fabrication plant in India planned to upgrade its material handling line for heavier steel components. After technical discussions, the client selected a European-spec single girder solution positioned as a 5 ton overhead crane for flexible indoor use in India.

The project scope covered design, manufacturing, testing, and overseas delivery. The crane was configured with a 5 t lifting capacity, 23 m span, and 9 m lifting height, meeting FEM 2m (A5) duty requirements. For this India project, smooth inverter control was critical, so long and cross traveling speeds were set at 2–20 m/min, while lifting speed was 0.8/5 m/min. This 5 ton overhead crane met all compliance needs.

To suit operators, the 5 ton overhead crane was equipped with both remote control and pendant control. Power configuration included 0.8/4.9 kW lifting power, 0.45 kW cross travel power, and 2×1.1 kW long travel motors. Recommended P22 rails and festoon cable cross power ensured stable operation in India workshops.

Safety was a key decision factor for the India buyer. The 5 ton overhead crane integrated emergency stop, anti-collision system, limit switches, phase protection relays, voltage low protection, ground fault protection, short-circuit protection, over-heating protection, and power-off protection. Insulation grade F and IP54 protection allowed reliable use in India’s -20℃ to +40℃ environments.

After factory acceptance testing, the 5 ton overhead crane was shipped to India and installed on schedule. Commissioning confirmed low noise, precise positioning, and efficient workflow improvement. The client reported faster handling cycles and reduced labor intensity.

Design Drawing of 5 Ton European-spec Single Girder Overhead Crane for Sale to India:

Crane system of 5 Ton European-spec Single Girder Overhead Crane:

Main structure		Main girder	Welded box-section beam, mainly use material Q235B carbon structural steel strong and elegant, easy to maintain. Three-layer painting. One layer of epoxy zinc rich primer, two l ayers of acrylic polyurethane topcoat, wit h a film thickness of 80-120 microns
Lifting mechanism		Electric hoist	Inverter traveling speed and dual lifting speed. Reducer, drum, motors Insultation grade F Protection class IP54
		Drum	Self-produced. Drums made of high quality seamless steel processed by CNC machine.
		Wire rope	Rope structure 8×26SW, steel core
		Rope guide	High strength nylon material, installed on the winding drum to guide the wire rope, Prevent constant winding of steel wire and prolong the life of the drum
		Hook	Plain ‘C’ type, Swiveling on Thrust Bearing, safety latch, 360°rotation
Motors		Crane traveling motor	Special designed Squirrel-cage motor for the electric hoist. Maintenance free. Insulation grade F. Protection class IP54. Electromagnetic disc type brake system
		Hoist lifting and travelling motor	Three-in-one motor Frequency converting control, make the lifting smooth and stable. Totally enclosed type with splash lubrication. Electromagnetic disc type brake system Insulation grade F Protection class IP54.
		End carriages	Q235B carbon square hollow steel structure, provides horizontally travelling for the crane with three-in-one motors and buffers
		Wheels	Installed on the crane end carriages as drive wheels, high carbon steel material. Vacuum casting by our group, Intermedium quenching by top technique machinery antirust painting
Electric parts		Electric cabinet& contactors	CHINT brand, Schneider contactors Protection class IP54
		Festoon cable	Supply power for the trolley, C type cable track, safe and reliable
		Pendant control	Button: Up and down; left and right; front and back; start and stop; emergency; Safe and reliable
		Remote control	Radio frequency control Safe and reliable
		Frequency converter	Inovance brand,. Control the lifting and travelling motor, change the motor speed.
		Aviation plug	Easy to connect when installing
Protection system		Lifting limit switches	For lifting protection, prevent the hook from knocking the hoist
		Travel limit switches	For long travel, protect the crane before it crashes the object
		Overload limiter	Under overload condition, cut off the power of the crane, the screen can show the weight of lifting items.
		Buffer	Ployurethane material, used for anti-collision

Processing 5 Ton Overhead Crane:

Package and Delivery of 5 Ton European Overhead Crane:

Certifications of 5 Ton Overhead Crane:

Application of 5 Ton Single Girder Overhead Crane in India:

1. Economic Background: India’s economy is characterized by rapid industrial growth, expanding manufacturing capacity, and strong government support through initiatives. In this context, high value on cost-effective and scalable industrial equipment that supports productivity without excessive capital investment.
2. Role of the Single Girder Overhead Crane: The 5 ton single girder overhead crane is widely used in India due to its balanced lifting capacity and economical structure. A 5 ton overhead crane meets the needs of small and medium enterprises that dominate industrial landscape.
3. Manufacturing and Fabrication Applications: In India, the 5 ton overhead crane is commonly applied in steel fabrication workshops, machinery manufacturing plants, and auto-component factories. These facilities require reliable lifting equipment for raw materials, semi-finished parts, and assemblies.
4. Warehousing and Logistics Use: With the growth of logistics hubs and industrial parks in India, the 5 ton overhead crane is used for loading, unloading, and internal material handling.
5. Cost and Efficiency Advantages: India’s price-sensitive market favors equipment with low operating and maintenance costs. The 5 ton overhead crane offers reduced structural weight, lower power consumption, and simplified maintenance, aligning well with economic conditions in India.
